| 유형: | 스프라그 | 정밀 등급: | P0 |
|---|---|---|---|
| 밀봉 종류: | 봉인 | 재료: | GCR15 |
| 외경: | 35mm | 보어 크기: | 15 mm |
| 토크 용량: | 29Nm | MAX 오버런 (내부): | 3600 r/min |
| MAX 오버런 (OUTER): | 2000 r/min | 당기 톱크: | 0.01 n*m |
| 무게: | 50N | 베어링 하중 (CR): | 5950 n |
| 베어링 하중 (COR): | 3230 n | 작동 온도: | +100' Ｃ에 대한 -30' Ｃ |
| 샤프트 직경 공차: | 15-0.008-0.028 mm | ||
| 강조하다: | 15mm sprag clutch bearing,one way clutch bearing 35mm OD,BB15-2K-K cam clutch bearing |
||
| Attribute | Value |
|---|---|
| Applicable Industries | Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction works, Energy & Mining |
| Type | sprag |
| Precision Rating | P0 |
| Seals Type | sealed |
| Material | GCr15 |
| Outer diameter | 35 mm |
| Bore size | 15 mm |
| Torque Capacity | 29 Nm |
| Package | single box or as your requirements |
| Port | Shanghai, Ningbo |
| Delivery time | 10-15 Days |
| OEM | Accept |
| Item | BB15 2K-K |
|---|---|
| Material | GCr15 |
| Outer dia. | 35 mm |
| Bore size | 15 mm |
| Torque Capacity | 29 Nm |
| Max. Overrunning(inner race) | 3600 r/min |
| Max. Overrunning(outer race) | 2000 r/min |
| Model | Torque Capacity (N*m) | Max. Overrunning (r/min) | Drag Torque (N*m) | Weight (N) |
|---|---|---|---|---|
| BB15 | 29 | 3600 (inner) 2000 (outer) |
0.01 | 50 |
| Model | Shaft Dia. (mm) | Housing Dia. (mm) |
|---|---|---|
| BB15-2K-K | 15-0.008-0.028 | 35-0.018-0.002 |
Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in producing various cam clutches, one way bearings, and overrunning clutches with high technology.
Total less than 25 KG: Each in white box + 19*18*9cm box + 29*28*19CM carton box
Total Weight over 100KG: Carton box + Wooden Box / Wooden Pallet
Samples are available for quality verification.
Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
